MFS-B 25mm Deflection Floor Spring Mount
Our MFS spring mounts are available with higher deflection 25mm springs (titled MFS-B). Utilising our 30-B series springs enables the mounts to achieve lower natural frequencies and therefore improve isolation performance from typical gym activities, compared to the standard MFS mounts.
The higher deflection spring allows the mount to achieve a natural frequency of down to 6Hz and absorb lower frequency vibration. A galvanised top plate with predrilled holes is utilised for 100mm battens to be mounted on top, with further layers of board placed above this. See a typical floor build-up detail below. Other build-ups can also be used.
| Documents & Files |
|---|
Installation Photos
See a selection of installation photos of our MFS-B Lightweight Sprung Floating Floor system below:
