DNSB-A Sway Brace/Wall Tie
DNSB-A is a low frequency wall tie. This sway brace has a bolt end for stud walls or hooked end for masonry walls.
The DNSB range is our most popular acoustic wall tie. These sway braces are available in two different sizes and with various ends to suit different wall constructions. For wall cavities of 100mm or above, the central bolt is replaced with longer studding to meet the required cavity thickness. DNSB-A acoustic sway braces are supplied pre-compressed to ensure consistent acoustic isolation while tolerating a range of wall loads.
If you would like to order or learn more about this product please contact Mason UK’s acoustic engineers.
Cross section of an isolated block wall
Cross section of an isolated partition wall
| Installation Photos |
|---|
